Narotam Platinum Plus Plywood

A High-strength ply.

Narotam Platinum Plus Plywood

Incredible Features

An absolutely astonishing category of Plywood, the Narotam Platinum Plus Plywood give you 300% lifetime guarantee of strength, dimensional stability and durability, Crafted out entirely from Gurjan timber, both veneer and finished plywood are treated with preservatives.

S. No. Test Prescribed Minimum Value for Conformity Observed Value
1. Moisture Content Test
Not less than 5%
Not more than 15%
8.5%
2. Glue Shear Strength (In dry state)
Avg. F/L(N)
1324 & Above
Avg. F?L(N) W?F(%)
1580   65%
3.
Glue Shear Strength
(After 72 hours boiling)
981 & above 1285   56%
4.
Tensile Strength
Along with grain
Across the grain
54 N/sq.mm
34 N/sq.mm
82.3 N/sq.mm
52.5 N/sq.mm
5.
Static Bending Strength
Modules of Rupture
i) Along the grain
ii) Across the grain
Modulus of Elasticity
i) Along the grain
ii) Across the grain


49 N/sq.mm
29 N/sq.mm

7355 N/sq.mm
3923 N/sq.mm





8720 N/sq.mm
4632 N/sq.mm

Impeccable Utility

This ply is suitable for external use as it has a unique 'Weather Shield' due to which it can withstand any type of extreme climate.
