Narotam Flush Door

Incredible Features

Extremely durable, Flush Doors of Narotam are the most prefereed ones for making door shutters for homes and offices. This door is perfect in dimensions and also does not suffer de-lamination when exposed to changeable atmospheric conditions. This door is made from single species of hardwood timber and the battens are individually treated. It is available in both commercial and decorative grades.

S. No. Test Prescribed in IS:2202 (Part-I), 1999 Minimum Value for Conformity Observed Value
1.
Dimension & squareness test as per IS:4020 (Part-2), 1998
Height & width shall be measured within an accuracy of 1.0 mm
Within specified limit
2.
General flatness test as per IS:4020 (Part-3), 1998
Squarness shall be measured to an accuracy of 1.0 mm
Within specified limit
3.
Local planeness test as per IS:4020 (Part-4), 1998
Planeness will be measured to an accuracy of 0.1 mm
Within specified limit
4.
Impact Indentation test as per IS:4020 (Part-5), 1998
Indentation will be measured to an accuracy of 0.1 mm
Within specified limit
5.
Flexure test as per IS:4020 (Part-6), 1998
The deflections will be measured to an accuracy of 0.1mm.
Within specified limit
6.
Edge loading test as per IS:4020 (Part-7), 1998
The deflections shall be measured to an accuracy of 0.1mm.
Within specified limit
7.
Shock resistance test as per IS:4020 (Part-8), 1998
4 to 5 shocks/min
Within specified limit
8.
Buckling test as per IS:4020 (Part-9), 1998
Deformation is measured to an accuracy of 1 mm, 5 min. after application of the load and 15 min after unloading
Within specified limit
9.
Slamming test as per IS:4020 (Part-10), 1998
50 times on the nail at the rate of 4-5 drops/min
Found O.K.
10.
Misuse test as per IS-4020 (Part-11), 1998
It should pass after applying 200 N force to the handle at right angle to the plane of the frame.
Satisfactory
11.
Varying humidity test as per IS:4020 (Part-12), 1998
Deviation shall be measured to an accuracy of 1.00 mm
Within specified limit
12.
End immersion test as per IS:4020 (Part-13), 1998
These shall be no de-lamination
No de-laminaton found Excellent
13.
Knife test as per IS:4020 (Part-13), 1998
Minimum pass standard There shall be no de-lamination
No de-laminaton found
14.
Glue adhesion test as per IS:4020 (Part-15), 1998
There shall be no de-lamination
Within specified limit
15.
Screw withdraw test as per IS:4020 (Part-16), 1998
Applied load shall be 2.00 mm per min for complete withdrawal of the screw within specified limit


Impeccable Utility

These Flush Doors are completely safe and 'Burglar Proof' too. Not only this they are stylish, adding glamour to your interior.
