Narotam Marine Plywood

A Daring Ply.

Narotam Club Plywood

Incredible Features

Marine Plywood is an exterior grade Plywood having the potential to bear alternate wetting and drying, when exposed to severe exterior conditions. It is bonded with Phenol Formaldehyde Synthetic Resin adhesive, which makes it long lasting even in water- prone areas. It is BWP Grade Plywood.

S. No. Test Prescribed in IS:710-1976 Minimum Value for Conformity Observed Value
1. Moisture Content Test
Not less than 5%
Not more than 15%
9%
2. Glue Shear Strength (In dry state)
Min. Ind 1100 N
Avg. 1350 N
1350 N
1550 N
3. Adhesion of Piles Minimum pass standard Excellent
4.
Glue Shear Strength
(After 72 hours boiling)
Min 800 N
Avg. 1000 N
1150 N
1250 N
5.
Tensile Strength
Along the grain
Across the grain
Sum of Tensile Strength

4200 N/sq.mm
2500 N/sq.mm
8450 N/sq.mm

5500 N/sq.mm
3900 N/sq.mm

6.
Static Bending Strength
Modules of Rupture
i) Along the grain
ii) Across the grain
Modulus of Elasticity
i) Along the grain
ii) Across the grain


49 N/sq.mm
29 N/sq.mm

8000 N/sq.mm
4000 N/sq.mm


65 N/sq.mm
40 N/sq.mm

8305 N/sq.mm
4170 N/sq.mm

Impeccable Utility

Marine Plywood is best suited for the manufacture of marine crafts, boats, riverine equipments, tanks of liquid chemicals and all other extreme temperature applications.
